| MACHINE SIZE (Ton) | Fits AdvanceQuip excavators | WEIGHT (kg) | AUX. HYD REQUIREMENTS | HYD COUPLERS | HITCH PICK-UP WIDTH (mm) | HITCH PIN CENTRES (mm) | HITCH PIN DIAMETER (mm) |
| 2.0-2.9 | CASE CX25D/CX26C | 120 | 1 x Pressure, 1 x Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 130 | 180 | 35 |
| 3.0-4.0 | CASE CX37C | 210 | 1 x Pressure, 1 x Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 140 | 185 | 40 |
| 5.0-6.0 | CASE CX60C | 210 | 1 x Pressure, 1 x Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 165 | 285 | 45 |
| 7.0-8.0 | CASE CX75CSR | 400 | 1 x Pressure, 1 x Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 200 | 310 | 50 |
| 10.0-14.5 | CASE CX130C/CX145CSR | 900 | 1 x Pressure, 1 x Return | 1″ ISO Screw Couplers, 1 x M, 1 x FM | 265 | 370 | 65 |
| 16.0-23.5 | CASE CX210C/CX235CSR | 1650 | 1 x Pressure, 1 x Return | 1″ ISO Screw Couplers, 1 x M, 1 x FM | 330 | 455 | 80 |
