| MODEL | MACHINE SIZE (Ton) | Fits AdvanceQuip excavators | WEIGHT (kg) | WIDTH (mm) | AUX. HYD REQUIREMENTS | HYD COUPLERS | MAX OIL FLOW (lpm) | MAX PRESSURE (Bar) | HITCH PICK-UP WIDTH (mm) | HITCH PIN CENTRES (mm) | HITCH PIN DIAMETER (mm) |
| DMV04 | 2.0-3.0 | CASE CX25D, CX26C | 145 | 320 | 1 x Pressure, 1 x Pressureless Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 34 | 195 | 190 | 185 | 35 |
| DMV04 | 3.0-4.0 | CASE CX37C | 145 | 320 | 1 x Pressure, 1 x Pressureless Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 34 | 195 | 145 | 200 | 40 |
| DMV08 | 5.0-6.0 | CASE CX60C | 360 | 500 | 1 x Pressure, 1 x Pressureless Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 67 | 195 | 175 | 250 | 45 |
| DMV08 | 7.0-8.0 | CASE CX75CSR | 360 | 500 | 1 x Pressure, 1 x Pressureless Return | 1/2″ ISO Poppit QRC, 1 x M, 1 x FM | 67 | 195 | 205 | 300 | 50 |
| DMV16 | 10.0-14.5 | CASE CX130C, CX145CSR | 730 | 760 | 1 x Pressure, 1 x Pressureless Return | 1″ ISO Screw Couplers, 1 x M, 1 x FM | 108 | 195 | | | 65 |
| DMV16 | 16.0-23.5 | CASE CX210C, CX235CSR | 730 | 760 | 1 x Pressure, 1 x Pressureless Return | 1″ ISO Screw Couplers, 1 x M, 1 x FM | 108 | 195 | | | 80 |
